Product Range
Engineered to Spec.
Ready When You Are.
Structural elements, drainage solutions, and custom precast -- manufactured to BS, Eurocode, and Ghana Standards.
Category 01
Structural Elements
Precast Columns
Square and rectangular reinforced precast columns for framed structures. Available in standard sections or custom dimensions to match your structural engineer's specification.
| Section Sizes | 200x200mm to 600x600mm |
| Concrete Grade | C30 to C50 |
| Standard Lengths | 3m, 4m, 5m, 6m (custom available) |
| Standards | BS 8110, EN 1992 (Eurocode 2) |
Typical Applications
Industrial buildings, warehouses, commercial frames, elevated structures.
Precast Beams
Rectangular and inverted T-beams for floor and roof applications. Prestressed options available for longer spans and heavier loads.
| Beam Types | Rectangular, Inverted T, L-Beam |
| Span Range | 4m to 20m |
| Prestressed | Available for spans over 8m |
| Concrete Grade | C40 to C50 |
Typical Applications
Floor systems, roof structures, bridges, elevated roadways.
Hollow Core Slabs
Prestressed hollow core flooring units offering fast, clean installation with reduced dead load. Ideal for residential, commercial, and car park structures.
| Depths Available | 150mm, 200mm, 265mm, 320mm, 400mm |
| Standard Width | 1,200mm |
| Max Span | Up to 16m (depth-dependent) |
| Fire Rating | REI 60 / REI 90 available |
Typical Applications
Residential floors, office buildings, hospitals, car parks, hotels.
Wall Panels
Solid and insulated precast wall panels for cladding and structural applications. Architectural finish options available including exposed aggregate and form-liner textures.
| Panel Types | Solid, Double Wythe Insulated, Sandwich |
| Thickness | 100mm to 300mm |
| Max Panel Size | Up to 3.0m x 9.0m |
| Finishes | Smooth, exposed aggregate, textured |
Typical Applications
External cladding, boundary walls, industrial buildings, security perimeters.
Category 02
Drainage Solutions
Box Culverts
Reinforced precast box culverts for road crossings, stream diversions, and highway drainage. Available in Class A, B, and C loading to AASHTO and Ghana Highway Authority standards.
U-Drain Channels
Open U-shaped drainage channels for surface water collection in roads, industrial yards, and landscaping. Smooth invert for optimal hydraulic flow.
Manholes
Circular and rectangular precast manholes and inspection chambers for sewer and stormwater infrastructure. Supplied complete with steps and cover slab.
Category 03
Special Elements
Retaining Wall Panels
Cantilever retaining wall panels for embankments, cut slopes, and terraced landscapes. Designed to your geotechnical engineer's specification.
Up to 6m retained height. Battered or vertical face.
Kerb Stones
Standard and mountable kerb stones in grey and exposed aggregate finishes. Manufactured to Ghana Standards Authority and BS 7263 specifications.
Standard, Dropper, Quadrant, Transition units available.
Custom Elements
Anything not listed above. AGC PreCast works from your shop drawings or collaborates from concept to deliver bespoke precast solutions.
Send us your drawings -- we will quote within 48 hours.
Resources
Technical Documentation
Product specifications, test reports, and installation guides. Request the documents you need.
Specification Sheets
Detailed specifications for all AGC PreCast elements including dimensions, tolerances, concrete grades, and reinforcement details.
Request SpecsInstallation Guides
Step-by-step installation instructions covering element handling, temporary propping, grouting, and final connections.
Request GuideTest Certificates
ISO-certified test results including 28-day cube strengths, dimensional inspection reports, and third-party structural load tests.
Request CertificatesCAD Drawings
DWG and DXF files for standard element sections. Available for project specifications and structural calculations.
Request CADsNot sure which product is right for your project?
Use our interactive comparison tool to evaluate columns, beams, hollow core slabs, wall panels, and drainage systems side by side. Compare specs, lead times, and applicable standards in one view.
